Free PFT interpretation chart

Key takeaways

A PFT interpretation chart turns spirometry, lung volume, and DLCO numbers into one diagnostic pathway you can follow in order.

Read the FEV1/FVC ratio first, grade severity from FEV1 percent predicted, then use TLC to separate obstruction from restriction.

DLCO shows how well gas crosses into the blood, and a value under 40% predicted needs specialist review.

A low FVC on its own never confirms restriction, so check lung volumes before you record that diagnosis.

Practice management software like Pabau stores the report, your interpretation, and the follow-up plan in one patient record.

Pulmonary function tests, known as PFTs, measure how much air the lungs move and how well they pass oxygen into the blood. A PFT interpretation chart turns those numbers into a decision pathway you work through in order.

Interpretation of lung function test results comes down to four questions asked in a fixed order. Is the ratio reduced? How severe is the defect? Does total lung capacity confirm restriction? Does gas transfer hold up?

This guide answers each question with the number that decides it. You also get every pattern in one table, plus two worked reports read end to end. A later section names the three misreads that send clinicians down the wrong track.

What is a PFT interpretation chart?

A PFT interpretation chart is a reference sheet that sets out the diagnostic thresholds and decision pathways for reading lung function results. It carries the cut-off values for the FEV1/FVC ratio and the percent predicted severity grades. It also lists the TLC thresholds that separate obstructive, restrictive, and mixed ventilatory defects.

You will see the same tool called a PFT interpretation cheat sheet or a PFT normal values chart. Both names cover the same content, which is a set of thresholds plus the order you apply them in. A PFT interpretation PDF is simply the printable version you keep beside the spirometer.

A shared chart also keeps interpretation consistent between colleagues, which matters when several people follow one patient. The StatPearls review of pulmonary function testing sets out the same order of operations.

Most charts hold four sections. Spirometry values come first, then lung volumes, then diffusing capacity. A pattern matrix closes the chart, tying each combination of results to a diagnosis and a severity grade. The strongest versions add worked PFT interpretation examples, so you can check your reading against a completed report.

The four core components of a complete PFT

A complete test rests on four measurements, and each one answers a different clinical question. Every PFT normal values chart is built around the same four:

• Spirometry (FEV1, FVC, FEV1/FVC ratio, flow rates): Measures how much air the lungs can push out and how fast. Normal PFT values for both FEV1 and FVC sit at 80% predicted or above. The FEV1/FVC ratio is the primary screening value, and a reduced ratio points to airflow obstruction.
• Lung volumes (TLC, RV, FRC): Measures total lung capacity and the air left after a full exhalation. Body plethysmography is the reference method here, with gas dilution as the fallback where no body box is available. A reduced TLC indicates restriction, while a raised RV suggests air trapping or emphysema.
• Diffusing capacity (DLCO): Measures how efficiently oxygen crosses from the alveoli into the bloodstream. A reduced DLCO points to parenchymal or vascular disease, whatever the airflow numbers say.
• Flow-volume loop: Plots airflow through forced inspiration and expiration. The shape of the loop confirms the pattern and can flag an upper airway problem the numbers alone would miss.

The PFT interpretation chart at a glance

Every value you need sits in the table below, with its normal range, the threshold that makes it abnormal, and what crossing that threshold means. Most references split these readings across separate tables, so the reading takes longer than it should.

Two caveats keep the table honest. Percent predicted is a shortcut, and the lower limit of normal is the more accurate boundary at both ends of life. Where your lab reports z-scores, a value below -1.645 marks that same boundary.

Abbreviations you will see on a lab report

Lab printouts abbreviate everything, and the lung volumes are the ones clinicians look up most often. This table keeps all of them in one place.

Step 1: Reading the FEV1/FVC ratio

Start with the FEV1/FVC ratio. It compares the air forced out in the first second with the total volume exhaled, and a reduced ratio means airflow obstruction. A normal FEV1/FVC ratio is 0.70 or higher, or at or above the lower limit of normal for that patient.

Critical threshold: a ratio below 0.70, or below the lower limit of normal, indicates obstruction. A ratio of 0.70 or higher rules obstruction out as the main defect, so move on and look for restriction instead.

Read the ratio next to the symptoms and history captured in the patient’s comprehensive assessment. The same number means different things in a smoker and a marathon runner.

The ratio catches obstruction that the absolute numbers miss. Mild COPD often shows a reduced ratio next to an FEV1 normal value of 80% predicted or above. That is why the ratio is read first and the grading comes second.

Asthma PFTs sit on this branch as often as COPD does. A reduced ratio in a younger patient with normal lung volumes leans toward asthma. Asthma PFT results can also look entirely normal between attacks, so a clean test never rules the diagnosis out.

Step 2: Grading severity from percent predicted

Grade severity from the FEV1 percent predicted, whichever pattern the ratio pointed to. An FVC normal value sits at 80% predicted or above, and so does FEV1. Grading starts the moment either drops below that line.

Percent predicted compares the patient’s FEV1 with the expected value for their age, height, and sex, using reference equations such as GLI 2012. Severity grading follows the American Thoracic Society scale below.

The same scale grades obstruction and restriction, so one vocabulary covers both patterns. That consistency is what lets a referral letter say “moderately severe” and mean the same thing to the pulmonologist reading it.

For COPD, the GOLD criteria run a parallel scale on the same FEV1 percent predicted value. GOLD 1 sits at 80% or above, GOLD 2 covers 50 to 79%, GOLD 3 covers 30 to 49%, and GOLD 4 falls below 30%. Both scales apply only after the ratio has confirmed obstruction.

ATS PFT interpretation rests on the 2022 ATS/ERS technical standard, which is still the current reference. Anything circulating as PFT interpretation guidelines for 2024 restates that same document. The ATS guidelines on pulmonary function testing also offer z-score grading instead of percent predicted. Check which scale your lab reports before you compare two results side by side.

Step 3: Telling obstruction and restriction apart

Total lung capacity is the value that separates obstructive vs restrictive lung disease on a pulmonary function test. A TLC at 80% predicted or above means obstruction, and a TLC below 80% predicted means restriction. This is the step that changes the treatment plan.

Obstructive pattern: FEV1/FVC below 0.70 with a normal or raised TLC, at 80% predicted or above. Air is trapped rather than restricted. Common causes are COPD, asthma, emphysema, and cystic fibrosis. Confirmed obstruction usually leads to inhaled therapy, which patients track on a medication schedule, alongside a COPD care plan where that is the diagnosis.

Restrictive pattern: FEV1/FVC at 0.70 or above with a TLC below 80% predicted. The lungs are mechanically limited rather than obstructed. Common causes are pulmonary fibrosis, sarcoidosis, chest wall disease, and neuromuscular weakness. Severe restriction can progress toward respiratory failure, so track these patients on a fixed review interval.

FVC behaves differently in each pattern, and that is where readings go wrong. In obstructive lung disease FVC often looks normal early on, then slides as air trapping worsens. In restriction it falls from the start, in step with the TLC.

Step 4: Interpreting DLCO

DLCO, the diffusing capacity of the lungs for carbon monoxide, measures how efficiently oxygen crosses from the alveoli into the blood. A low value narrows the differential quickly:

• Normal, above 75% predicted: gas exchange is intact, which argues against parenchymal disease.
• Mildly reduced, 60-75% predicted: consider early interstitial disease or early emphysema.
• Moderately reduced, 40-59% predicted: a significant defect, seen in pulmonary fibrosis, alveolitis, and moderate emphysema.
• Severely reduced, below 40% predicted: advanced pulmonary or vascular disease, including advanced IPF and pulmonary hypertension.

DLCO earns its place when spirometry looks normal but the patient is still breathless. That combination points toward early interstitial lung disease or pulmonary vascular disease. Where the picture stays unclear, cardiopulmonary exercise testing separates a lung cause from a cardiac or deconditioning cause.

Bronchodilator response: when reversibility changes the diagnosis

A positive bronchodilator response is a rise of at least 12% and 200 mL in FEV1 or FVC after an inhaled bronchodilator. One result can move a patient from a COPD label to an asthma one.

The 2022 ATS/ERS standard revised that threshold to a change of more than 10% of the predicted value for FEV1 or FVC. A borderline result can pass one criterion and fail the other.

Many labs still print the older 12% and 200 mL criterion, so read the footnote on the report before you call a response negative. Record in the note which criterion your lab applied.

What the post-bronchodilator numbers tell you depends on how far the obstruction reverses:

• Ratio returns to normal: obstruction that clears after the bronchodilator leans strongly toward asthma.
• Partial response, ratio still below 0.70: typical of COPD, and also seen in long-standing asthma with airway remodeling.
• No response: asthma stays on the list, because a single test can miss reversibility on a well-controlled day.

Repeat the test when the result contradicts the history. Testing during a symptomatic period, or after a trial of inhaled corticosteroids, often reveals reversibility that one baseline test missed. Where the diagnosis still will not settle, methacholine challenge testing looks for airway hyperresponsiveness instead.

Mixed ventilatory defects: When patterns overlap

A mixed ventilatory defect is an FEV1/FVC below 0.70 alongside a TLC below 80% predicted, so both mechanisms are present at once. It turns up in advanced COPD with coexisting fibrosis, in emphysema with chest wall disease, and in some occupational lung disease.

A mixed defect is a referral, not something to manage in general practice. Treatment aimed at one mechanism can worsen the other, so the reading needs a specialist before the plan is written.

One overlap pattern hides in plain sight. PRISm, short for preserved ratio impaired spirometry, shows a normal FEV1/FVC ratio with an FEV1 below 80% predicted.

Restriction needs a reduced TLC to confirm it, so a normal TLC keeps the patient in the PRISm group. These patients carry a higher risk of progressing to COPD, which makes repeat testing worthwhile. The FAQ below sets out the full definition.

Every PFT pattern in one table

Six patterns cover almost every report you will read, and each is a combination of three values: the ratio, the TLC, and the DLCO. The table below sets them side by side, with the severity scale and the guideline each threshold comes from.

The guideline column is there because two standards are still in circulation. The 2005 ATS/ERS document grades severity in percent predicted bands, and most lab printouts still use it.

The 2021 to 2022 ATS/ERS update grades on z-scores instead. Mild runs from -1.65 to -2.50, moderate from -2.51 to -4.00, and severe sits below -4.00.

Two reports on the same patient can therefore carry different severity labels. Check which scale the lab used before you compare a new result with an old one. Do the same before you quote a grade in a referral letter.

Worked example: Two sample reports read end to end

The two value sets below are illustrative rather than real patient data. They show how the same five steps resolve an obstructive report and a restrictive one.

Patient A branches into obstruction at step one. The FEV1 grades as moderately severe, and a TLC of 112% predicted confirms air trapping rather than restriction. The low DLCO and the flat bronchodilator response together point toward emphysema.

Patient B keeps a normal ratio, so restriction is the question from the start. A TLC of 68% predicted confirms it, and the FVC falls in step. The DLCO at 47% predicted points at the lung tissue itself, which makes interstitial disease the first thing to exclude.

Reading the flow-volume loop

PFT graph interpretation starts with shape rather than numbers. The loop plots airflow across the whole breathing cycle, and its outline usually confirms the pattern before you check a single value:

• Obstructive loop: a scooped, concave expiratory curve, reflecting reduced airflow throughout exhalation. Typical of COPD and asthma.
• Restrictive loop: small overall, but normal in shape. The curve stays smooth, with no scooping.
• Upper airway obstruction: flattened inspiratory or expiratory limbs, pointing to a fixed or variable narrowing at the larynx or trachea.
• Normal loop: a smooth, bell-shaped curve with good flow at the start and end of exhalation.

One habit is worth building. Read the spirometry graph before the numbers, because a poor effort shows up as a ragged or truncated curve. Values from a bad maneuver are not worth grading.

Three misreads the chart prevents

Most interpretation errors come from three habits rather than from hard cases. Each one is easy to catch if you know it is coming:

• Calling restriction from spirometry alone. A low FVC with a normal ratio suggests restriction, but only lung volumes confirm it. Plenty of these patients turn out to have a normal TLC and a non-specific pattern instead.
• Trusting the fixed 0.70 cut-off at both ends of life. The ratio falls with age, so 0.70 over-calls obstruction in older patients and misses it in younger ones. The lower limit of normal avoids both errors.
• Reading DLCO without the hemoglobin. Anemia lowers DLCO on its own. Check the adjusted value before you attribute a low result to lung disease.

How to use the chart at the point of care

Work the chart in one fixed order: ratio, then severity, then volumes, then gas transfer. The printable sheet at the top of this page carries the thresholds, the pattern matrix, and the reference ranges. Use it like this:

1. Find the FEV1/FVC ratio. Below 0.70 takes you down the obstruction pathway, and 0.70 or above sends you to look for restriction.
2. Read the FEV1 percent predicted against the severity scale to grade the defect.
3. Check the TLC to confirm whether the pattern is obstructive, restrictive, or mixed.
4. Read the DLCO to find any gas exchange problem and narrow the differential.
5. Match the combination against the conditions column, then write your impression and next step.

Five steps take under a minute once the chart is in front of you, and the order is what protects you. Skipping straight to a diagnosis is where the misreads above start.

A PFT interpretation calculator returns a pattern from the values you type in, then stops. A printed PFTs chart shows the reasoning behind each branch. You can see which threshold decided the answer, then defend it in a referral letter.

When to refer to a pulmonologist

Refer when the defect is severe, when the pattern is mixed, or when the numbers and the patient disagree. The chart doubles as a referral filter, and these findings all warrant specialist review:

• Very severe obstruction, with an FEV1 below 35% predicted, or very severe restriction with a TLC below 50% predicted
• A mixed ventilatory defect that needs the mechanism clarified
• An unexplained DLCO below 40% predicted with normal spirometry and lung volumes
• FEV1 values falling quickly across serial tests
• A clinical picture that does not match the numbers
• Any case still undiagnosed after the initial workup

Send the numbers, not just the conclusion. A patient discharge form or referral letter that carries the raw values, the reference equation, and your reading saves the specialist a repeat test.

Between referrals, serial testing is what shows the trend. Practices that track patient follow-up can see decline early, and physical therapy teams running pulmonary rehabilitation can record exercise tolerance against the same record.

How Pabau keeps PFT results and your interpretation together

In most practices the report and the reading live apart. The PDF comes back from the lab and gets filed. Your interpretation sits in a separate note, or in nobody’s note at all. At the next visit, someone spends five minutes hunting for both.

Practice management software like Pabau keeps them in one place. The report attaches to the patient records alongside your written impression, the severity grade, and the review date. Digital intake forms collect symptoms, smoking history, and current inhalers before the appointment, so the numbers arrive with their context.

Pabau Scribe, our AI scribe, drafts the consultation note while you talk the patient through the result. You review it, edit the interpretation, and sign it off before the patient reaches the door. The reading is recorded while it is fresh, and your evening is not spent catching up on notes.

Keep every PFT result inside the patient record

Pabau’s digital records, intake forms, and AI scribe hold test results, symptoms, and your interpretation in one patient file. Your team stops hunting through email and scanned PDFs before every review appointment.

Book a demo

Conclusion

The chart is worth less than the order you read it in. Ratio, severity, volumes, DLCO: work those four steps every time and most results resolve into a clear pattern within a minute.

What the chart will not do is overrule the patient in front of you. A number that disagrees with the clinical picture is a reason to check technique and repeat the test, not a reason to diagnose faster. Effort-dependent values reward a second look.

Keep the report, the interpretation, and the follow-up plan in one record, and the next clinician starts where you finished. Book a demo to see how Pabau keeps lung function results and clinical notes in the same patient file.
